A mature AC geared platform paired with an industrial VFD for projects that specify a conventional geared drive.
Compare This Family ↗
Ceiling Air Movement
AirMoveX AXV-ACB Series
Geared Six-Blade HVLS Fan
A mature AC geared platform paired with an industrial VFD for projects that specify a conventional geared drive.
- AC geared motor
- Industrial VFD
- Six AL6063 blades
- Established high-bay format
- Size Range
- 18-22 ft
- Drive
- AC geared motor
- Max Air Volume
- 12,800 m³/min
- Installation
- Recommended clear height ≥ 7 m
Product Overview
Configured Around The Building, Not Just The Diameter
A mature AC geared platform paired with an industrial VFD for projects that specify a conventional geared drive.
- Drive
- AC geared motor
- Blade
- AL6063 / 6 pcs
- Control
- Industrial VFD
- Install
- Recommended clear height ≥ 7 m
Warehouses, factories, barns, indoor gyms, stations and high-bay public buildings
Reference values support preliminary selection. Final voltage, size, control, installation accessories, certification scope and packing are confirmed in the quotation.
Why This Model May Fit
AirMoveX AXV-ACB Series In The AirMoveX System
Use this card as a preliminary fit check. It explains the role of the series from the catalog; the final model, voltage, accessories and installation scope still belong in the quotation.
Typical applications: Warehouses, factories, barns, indoor gyms, stations and high-bay public buildings.
Industrial VFD. Available variants begin at 6.72 m / 22 ft; review the table below for the series range.
Confirm voltage, selected size, accessories, certification scope, packing, delivery terms and the site installation method against the final configuration.
Carry This Model Into A Quote ↗Available Configurations
AirMoveX AXV-ACB Series Model Specifications
Select a preliminary configuration below. The inquiry button carries the exact series and model into the project form.
| AirMoveX Model | Diameter | Voltage | Power | Current | Max Speed | Max Air Volume | Coverage / Capacity | Sound | Blades | Net Weight | Inquiry |
|---|---|---|---|---|---|---|---|---|---|---|---|
| AXV-ACB22 | 6.72 m / 22 ft | 220/380 V / 50-60 Hz | 1,500 W | 3.7 A | 55 rpm | 12,800 m³/min | 1,100 m² | ≤ 45 dB(A) | 6 | 154 kg | Quote This Model ↗ |
| AXV-ACB20 | 6.12 m / 20 ft | 220/380 V / 50-60 Hz | 1,500 W | 3.7 A | 60 rpm | 12,200 m³/min | 1,000 m² | ≤ 45 dB(A) | 6 | 150 kg | Quote This Model ↗ |
| AXV-ACB18 | 5.52 m / 18 ft | 220/380 V / 50-60 Hz | 1,500 W | 3.7 A | 65 rpm | 11,900 m³/min | 900 m² | ≤ 45 dB(A) | 6 | 146 kg | Quote This Model ↗ |
